CT7035C Unfold All
Product Description
CT7035C is an analog output temperature sensor with an accuracy of ±0.35°C. By connecting to the A-to-D port of the MCU, NTC can be easily replaced. Very suitable for industrial thermal control and HVAC systems.
Product Features
  • 工作电压:1.8V至5.5V

  • 平均静态电流:7uA(典型值)

  • 温度精度:

        ±0.35°C(最大值),范围为10°C至30°C(K型)

        ±1.0°C(最大值),范围为-50°C至150°C(K型)

        ±1.5°C(最大值),从10°C到50°C(非K型)

        ±3.5°C(最大值)从-40°C到125°C(非K型)

  • 斜率增益多选[mV/°C]:

        CT7035LA, 19.5;              CT7035LB/J, 10.0

        CT7035LC, 6.25;             CT7035LD, -5.5

        CT7035LE, -8.2;             CT7035LF, -10.9

        CT7035LG, -11.77;           CT7035LH, -13.6

        CT7035LK, -5.8;

  • 输出短路保护

  • 温度范围:-50°C至150

Typical Application
Functional Block Diagram
Package

SOT-23

SC70-5

Datasheet
Ordering Information

Order PN

Slope Gain [mV/°C]

Green1

Package

Marking ID2

Packing

MPQ

Operation Temperature

CT7035LAKR

19.5

Halogen free

SOT-23

KEWX

Tape & Reel

3,000

-50°C ~ +150°C

CT7035LBKR

10.0

Halogen free

SOT-23

KFWX

Tape & Reel

3,000

-50°C ~ +150°C

CT7035LCKR

6.25

Halogen free

SOT-23

KGWX

Tape & Reel

3,000

-50°C ~ +150°C

CT7035LDKR

-5.5

Halogen free

SOT-23

KHWX

Tape & Reel

3,000

-50°C ~ +150°C

CT7035LEKR

-8.2

Halogen free

SOT-23

KJWX

Tape & Reel

3,000

-50°C ~ +150°C

CT7035LFKR

-10.9

Halogen free

SOT-23

KKWX

Tape & Reel

3,000

-50°C ~ +150°C

CT7035LGKR

-11.77

Halogen free

SOT-23

KLWX

Tape & Reel

3,000

-50°C ~ +150°C

CT7035LHKR

-13.6

Halogen free

SOT-23

KMWX

Tape & Reel

3,000

-50°C ~ +150°C

CT7035LJKR

10.0

Halogen free

SOT-23

KNWX

Tape & Reel

3,000

-50°C ~ +150°C

CT7035LKKR

-5.8

Halogen free

SOT-23

KPWX

Tape & Reel

3,000

-50°C ~ +150°C

CT7035LAKC5R

19.5

Halogen free

SC70-5

KQWX

Tape & Reel

3,000

-50°C ~ +150°C

CT7035LBKC5R

10.0

Halogen free

SC70-5

KRWX

Tape & Reel

3,000

-50°C ~ +150°C

CT7035LCKC5R

6.25

Halogen free

SC70-5

KSWX

Tape & Reel

3,000

-50°C ~ +150°C

CT7035LDKC5R

-5.5

Halogen free

SC70-5

KTWX

Tape & Reel

3,000

-50°C ~ +150°C

CT7035LEKC5R

-8.2

Halogen free

SC70-5

KUWX

Tape & Reel

3,000

-50°C ~ +150°C

CT7035LFKC5R

-10.9

Halogen free

SC70-5

KYWX

Tape & Reel

3,000

-50°C ~ +150°C

CT7035LGKC5R

-11.77

Halogen free

SC70-5

KZWX

Tape & Reel

3,000

-50°C ~ +150°C

CT7035LHKC5R

-13.6

Halogen free

SC70-5

LAWX

Tape & Reel

3,000

-50°C ~ +150°C

CT7035LJKC5R

10.0

Halogen free

SC70-5

LBWX

Tape & Reel

3,000

-50°C ~ +150°C

CT7035LKKC5R

-5.8

Halogen free

SC70-5

LCWX

Tape & Reel

3,000

-50°C ~ +150°C
